12.6.3.2 High resolution
Reading distance in mm (inch) 1
300
(11.81)
250
(9.84)
200
(7.87)
150
(5.91)
100
(3.94)
50
(1.97)
0
250
(9.84)
200
(7.87)
150
(5.91)
100
(3.94)
50
(1.97)
0
Focus position in mm (inch)
2
Resolution 0.15 mm (5.9 mil) 3
Max. reading distance (aperture angle 25°) 4
Min. reading distance 5
A
B
A
B
Figure 67: Reading field diagram CLV642, resolution 0.15 mm, reading window on front
1
Reading distance in mm (inch)
2
Focus position in mm (inch)
3
Resolution 0.15 mm (5.9 mil)
4
Max. reading distance (aperture angle 25°)
5
Min. reading distance
12.6.4 Overview of CLV65x reading field diagrams
12.6.4.1 standard resolution
0
600
(23.62)
1,000
(39.37)
1,400
(55.12)
1,800
(70.92)
200
(7.87)
a
b
c
d
Reading field height in mm 1
Reading distance in mm 2
400
(15.75)
200
(7.87)
–200
(
–7.87)
–400
(–15.75)
0
Resolution 3
a: 0.25 mm (9.8 mil)
c: 0.50 mm (19.7 mil)
d: 1.00 mm (39.4 mil)
b: 0.35 mm (13.8 mil)
Figure 68: Reading field diagram CLV650, reading window on front
1
Reading field height in mm (inch)
2
Reading distance in mm (inch)
3
Solution
TECHNICAL DATA 12
