SICK CLV65 Series - Page 92

0
600
(23.62)
1,000
(39.37)
1,400
(55.12
1,800
(70.92)
200
(7.87
a
b
c
d
Reading field height in mm 1
Reading distance in mm 2
400
(15.75)
200
(7.87)
–200
(
–7.87)
–400
(–15.75)
0
Resolution 3
a: 0.25 mm (9.8 mil)
c: 0.50 mm (19.7 mil)
d: 1.00 mm (39.4 mil)
b: 0.35 mm (13.8 mil)
Figure 69: Reading field diagram CLV650, oscillating mirror, reading window on side
1
Reading field height in mm (inch)
2
Reading distance in mm (inch)
3
Solution
400
(15.75)
500
(19.69)
100
(3.94)
200
(7.87)
300
(11.81)
–400
(–15.75)
–500
(–19.69)
–100
(–3.94)
–200
(–7.87)
–300
(–11.81)
0
400
(15.75)
600
(23.62)
800
(31.50)
1,000
(39.37)
1,200
(47.24)
1,400
(55.12)
200
(7.87)
0
Reading distance in mm (inch)
2
For devices with plastic reading window, the depth of
field is reduced by approx. 10 %. 3
Resolution 4
a: 0.25 mm (9.8 mil)
c: 0.50 mm (19.7 mil)
d: 1.00 mm (39.4 mil)
b: 0.35 mm (13.8 mil)
Reading field height in mm (inch)
1
a
b
c
d
Figure 70: Reading field diagram CLV650-0120S01, reading window on front, variants with polarizing filters
1
Reading field height in mm (inch)
2
Reading distance in mm (inch)
3
The depth of field is reduced by approx. 10% for devices with plastic lenses.
4
Solution
12 TECHNICAL DATA
92
O P E R A T I N G I N S T R U C T I O N S | CLV63x, CLV64x, CLV65x 8019588/129Z/2019-02-07 | SICK
Subject to change without notice
