SICK CLV65 Series - Page 93

Deflection range in mm (inch) 1
Reading distance in mm (inch) 2
800
(31.50)
0
0 1 400
(55.12)
40° 20°
1 600
(62.99)
Resolution 3
a: 0.25 mm (19.7 mil)
b: 0.35 mm (13.8 mil)
–800
(–31.50)
c: 0.50 mm (19.7 mil)
d: 1.00 mm (39.5 mil)
1 800
(70.87)
b
a
d
c
–200
(–7.87)
–600
(–23.62)
600
(23.62)
–400
(–15.75)
400
(15.75)
–200
(–7.87)
200
(7.87)
200
(7.87)
400
(15.75)
600
(23.62)
800
(31.50)
1 000
(39.37)
1 200
(47.24)
Figure 71: Oscillating mirror deflection widths diagram CLV650, standard density, oscillating mirror
1
Deflection width in mm (inch)
2
Reading distance in mm (inch)
3
Solution
TECHNICAL DATA 12
8019588/129Z/2019-02-07 | SICK O P E R A T I N G I N S T R U C T I O N S | CLV63x, CLV64x, CLV65x
93
Subject to change without notice
