12.6.4.2 Low resolution
Reading field height in mm (inch) 1
500
(19.69)
400
(15.75)
300
(11.81)
200
(7.87)
100
(3.94)
–100
(–3.94)
–200
(–7.87)
–300
(–11.81)
–400
(–15.75)
–500
(–19.69)
0
0 1,000
(39.37)
200
(7.87)
400
(15.75)
600
(23.62)
800
(31.5)
Resolution 3
a: 0.50 mm (19.7 mil)
a
Reading distance in mm (inch) 2
Figure 72: Reading field diagram CLV651, reading window on front
1
Reading field height in mm (inch)
2
Reading distance in mm (inch)
3
Solution
Reading field height in mm (inch) 1
500
(19.69)
400
(15.75)
300
(11.81)
200
(7.87)
100
(3.94)
–100
(–3.94)
–200
(–7.87)
–300
(–11.81)
–400
(–15.75)
–500
(–19.69)
0
0 1,000
(39.37)
200
(7.87)
400
(15.75)
600
(23.62)
800
(31.5)
Resolution
3
a: 0.50 mm (19.7 mil)
Reading distance in mm (inch) 2
a
Figure 73: Reading field diagram CLV651, oscillating mirror, reading window on side
1
Reading field height in mm (inch)
2
Reading distance in mm (inch)
3
Solution
