12 Ordering information
12.1 Scope of delivery
Scope of delivery, IME2S
•
1 × IME2S s
afety switch
•
2 × fixing nuts
•
1 × safety notes
•
Operating instructions for download: www.sick.com
Scope of delivery, IQB2S
•
1 × IQB2S safety switch
•
1 × safety notes
•
Operating instructions for download: www.sick.com
12.2 Ordering information
Table 21: IME2S ordering information
Design Housing diame‐
t
er
Sensor connec‐
tion type
Structural state Type code Part number
Cylindrical M12 Cable with M12
male connector,
4-pin
Flush IME2S12-04B4DQ9 1091142
Cylindrical M12 Cable with M12
male connec
tor,
4-pin
Non-flush IME2S12-04N4DQ9 1091943
Cylindrical M12 M12 male con‐
nector, 4-pin
Flush IME2S12-04B4DC0 1091944
Cylindrical M12 Open cable Flush IME2S12-04B4DW2 1091945
Cylindrical M12 M12 male con‐
nec
tor, 4-pin
Non-flush IME2S12-04N4DC0 1091946
Cylindrical M12 Open cable Non-flush IME2S12-04N4DW2 1091947
Cylindrical M12 M12 male con‐
nector, 4-pin
Non-flush IME2S12-08N4DC0 1091948
Cylindrical M18 M12 male con‐
nec
tor, 4-pin
Flush IME2S18-05B4DC0 1091949
Cylindrical M18 M12 male con‐
nector, 4-pin
Non-flush IME2S18-08N4DC0 1091950
Cylindrical M18 M12 male con‐
nec
tor, 4-pin
Flush IME2S18-08B4DC0 1091951
Cylindrical M30 M12 male con‐
nector, 4-pin
Flush IME2S30-12B4DC0 1091952
Cylindrical M30 M12 male con‐
nector, 4-pin
Non-flush IME2S30-15N4DC0 1091953
Table 22: IQB2S ordering information
Design Dimensions (W x
D x H)
Sensor connec‐
t
ion type
Structural state Type code Part number
Cuboid 12 mm × 40 mm
× 26 mm
M8 male con‐
nector, 4-pin
Flush IQB2S12-04B4DT0 1091954
Cuboid 12 mm × 40 mm
× 26 mm
Open cable Flush IQB2S12-04B4DW2 1091955
12 ORDERING INFORMATION
34
O P E R A T I N G I N S T R U C T I O N S | IME2S, IQB2S 8023341/17AZ/2020-03-24 | SICK
Subject to change without notice
