3 PRODUCT DESCRIPTION
3.1 Safety switch
Function
● Detection of upper protection hood position
This ensures that the open protection hood does not affect the scanning field.
Fig. 2: Safety switch
3.2 Cable fasteners
Cable fasteners should be laid as shown in Fig. 3:.
Fig. 3: Cable fasteners on the safety laser scanner and feed-through to the rear
Legend
1
Safety switch
Further information on the IME2S safety switch can be found in the correspond-
ing SICK operating instructions.
