Further topics
•
"T
echnical data", page 34
4.4.5 Cascading
Several safety switches can be connected using cascading. The connected devices act
lik
e one device.
Structure of a cascade
A cascade can be structured as follows:
•
Connecting the safety switches with M12 plug connectors, terminating the cas‐
cade with an end connector (only for variant with 2 M12 plug connectors)
•
Connecting the safety switches with special T-connectors, terminating the cascade
with an end connector (only for variant with 8-pin M12 plug connector)
DANGER
B
ypassing the protective device
The dangerous state may not be stopped in the event of non-compliance.
1. If a cascade is created with directly connected safety switches, the connecting
cable must be mounted so that a safety switch cannot be easily jumpered; e.g.,
cover plug connector or protect against access with additional means (e.g., protec‐
tive cover with disposable screws).
2. If a cascade is created with T-connectors, the connecting cable must be mounted
so that individual T-connectors (and therefore a safety switch) cannot be easily
jumpered.
Both connection methods can be combined as desired.
