SICK MLP1 - 11 Technical Data

11 Technical data
11.1 Technical data
Table 11: Features
Features
Safe switch on distance S
ao
4 mm
Typical switch on distance S
o
15 mm
Safe switch off distance S
ar
45 mm
Max. actuation frequency 0.5 Hz
Locking force 500 N
Magnetic retaining force when not supplied
w
ith power
25 N
Alignment tolerance for locking device
Vertical 5 mm
Horizontal 5 mm
Aperture angle 3°
Table 12: Safety-related parameters
Safety-related parameters
Performance level PL e (ISO 13849-1)
1)
Category 4 (ISO 13849)
Safety integrity level SIL 3 (EN 61508)
SIL claim limit SILCL 3 (EN 62061)
PFHd (mean probability of a dangerous failure
per hour)
1.5 × 10
–8
a
t 40 °C and 1,000 m above seal
level
T
M
(mission time) 20 years (ISO 13849-1)
Type Type 4 (ISO 14119)
Coding level Low coding level (ISO 14119)
Safe state when a fault occurs At least one OSSD is in the OFF state
1)
In a cascade, the performance level for the cascade as a whole depends on the number and type of
de
vices in the cascade. PL e is only possible in cascades with a maximum of 6 devices.
Table 13: Interfaces of variant with 1 × M12 plug connector, 5-pin
Interfaces of variant with 1 × M12 plug connector, 5-pin
System connection
Voltage supply
L
ocal inputs and outputs
Male connector, M12, 5-pin, A-coded (common
plug connector for voltage supply and outputs)
Length of connecting cable 150 mm
Table 14: Interfaces of variant with 2 × M12 plug connector, 5-pin
Interfaces of variant with 2 × M12 plug connector, 5-pin
System connection
Voltage supply
Local inputs and outputs
Male connector, M12, 5-pin, A-coded (common
plug connector for voltage supply and outputs)
Female connector, M12, 5-pin, A-coded (com‐
mon plug connector for voltage supply and
inputs)
Length of connecting cable 150 mm
11 TECHNICAL DATA
34
