5
4
3
2
1
Figure 19: Internal circuitry: end connector for series connection
Node
s for voltage supply
Table 29: Nodes for voltage supply ordering information
Part Type code Part number
Nodes for voltage supply MLP1-XXN 1078202
55
44
33
22
1
1
5
4
3
2
1
Figure 20: Internal circuitry: nodes for voltage supply ordering information
ACCESSORIES 14
8020169/ZJN1/2018-03-21 | SICK O P E R A T I N G I N S T R U C T I O N S | MLP1
43
