7 Operation and parameter settings
Display mode
(2 s)
Programming
mode
Description
Value range Factory settings
SP1/FH1 Value Switching point 1/upper window limit 1 Min: LLR +0.2% of the range, max: ULR ULR
RP1/FL1 Value Reset point 1/lower window limit 1 Min: LLR, max: ULR -0.2% of the range ULR - 10%
SP2/FH2 Value Switching point 2/upper window limit 2 (if second switching output
Min: LLR +0.2% of the range, max: ULR ULR
is available and not congured in diagnosis mode)
RP2/FL2 Value
Reset point 2/lower window limit 2 (if second switching output
is available and not congured in diagnosis mode)
Min: LLR, max: ULR -0.2% of the range ULR - 10%
EF RES YES/NO
Resets the set parameters to the factory settings (also resets the
saved HIGH and LOW values)
DS1 Value Switching delay 1 0 to 50 s 0 s
DR1 Value Reset delay 1 0 to 50 s 0 s
DS2 Value Switching delay 2 (if second switching output is available) 0 to 50 s 0 s
DR2 Value Reset delay 2 (if second switching output is available) 0 to 50 s 0 s
OU1 PARA
Switching function, switching output 1:
Hysteresis function, normally open: HNO
Hysteresis function, normally closed: HNC
Window function, normally open: FNO
Window function, normally closed: FNC
HNO, HNC, FNO, FNC HNO
