9 Technical data
63
(2.48)
35
(1.38)
M12x1
12
(0.47)
G1/4
25.8
(1.02)
13.6
(0.54)
9.5
(0.37
)
9.5
(0.37
)
G1/4
35
(1.38)
13.6
(0.54)
Figure 17: PAC50 with G¼ process connection
Dimensional drawings
Dimensions in mm (inch)
13.6
(0.54)
25.8
(1.02)
9.5
(0.37)
2.8
(0.11
) G1/4
Push-in fitting
ø 4.0 (ø 0.16)
M12x1
12
(0.47)
63
(2.48)
35
(1.38)
35
(1.38)
13.6
(0.54)
Figure 18: PAC50 with push-in tting
