10 Technical data
NOTE
The relevant online data sheet for your product, including technical data, dimensional
drawing, and connection diagrams can be downloaded, saved, and printed from the
Internet:
•
www.sick.com/TriSpectorP1000
Please note: This documentation may contain further technical data.
10.1
Features
Type Value
Tasks Positioning, inspection, measuring, reading
Technology 3D, line scan, image analysis
Working distance (mea‐
sured from front window)
1008: 56...116 mm range
1030: 141...541 mm range
1060: 291...1091 mm range
Example field of view 1008: 65 mm x 15 mm
1030: 270 mm x 100 mm
1060: 540 mm x 200 mm
Width at minimum work‐
ing distance
1008: 40 mm
1030: 90 mm
1060: 180 mm
Width at maximum work‐
ing distance
1008: 75 mm
1030: 330 mm
1060: 660 mm
Maximum height range 1008: 60 mm
1030: 400 mm
1060: 800 mm
Factory calibrated Yes
Light source Visible red light (laser, 660 nm)
Laser class 2 (EN/IEC 60825-1:2014)
2M (EN/IEC 60825-1:2007)
Complies with 21 CFR 1040.10 except for deviations pursuant to
Laser Notice No. 50, dated June 24, 2007
Laser fan angle 45°±2°
Imaging angle 1008/1030: 65°
1060: 67°
Offline support Emulator
10.2 Ambient data
Type Value
EMC Immunity: EN 61000-6-2:2005
Emission: EN 61000-6-3:2007
Shock load 15 g / 6 ms (EN 60068-2-27)
Vibration load 5 g, 10 Hz...150 Hz (EN 60068-2-6)
Ambient operating temper‐
ature
0 °C ... +40 °C (adequate heat dissipation is required,
see "Mounting the device", page 22)
10 TECHNICAL DATA
44
O P E R A T I N G I N S T R U C T I O N S | TriSpectorP1000 8022395/19OK/2020-12 | SICK
Subject to change without notice
