10.5 Input switching levels
Type Value
Input levels Up to 30 V
Stresses beyond this over-voltage level can cause permanent dam‐
age to the device.
Input threshold levels High: > 15.0 V
Low: < 5.0 V
Hysteresis > 1.0 V
Input current High: < 3.0 mA
Low: < 0.1 mA
10.6 Output switching levels
Type Value
Voltage level high High: > Voltage Supply - 3.0 V
(Voltage Supply = 19.2 V...28.8 V)
Low: < 2.0 V
Source/sink output current ≤ 100 mA at 24°C
Overcurrent protection < 200 mA
Capacitive load ≤ 100 nF
Inductive load ≤ 1H (with use of external free-wheeling diode, otherwise perma‐
nent damage to the device can occur)
10.7 Performance
Type Value
Height resolution 1008: 20 ... 50 μm
1030: 40 ... 280 μm
1060: 80 ... 670 μm
Scan/frame rate 5000 3D profiles/s
Maximum number of pro‐
files
2500 per image
3D profile resolution 1008: 0.049 mm/px
1030: 0.215 mm/px
1060: 0.43 mm/px
