WTF12L-xxxxx1xx:
0
2
(0.08)
100
(3.94)
200
(7.87)
300
(11.81)
0
y
x
Minimum object height in mm (inch)
Example:
Reliable detection of the object
Background
Distance in mm (inch)
Recommended sensing range for
the best performance
12
(0.47)
10
(0.39)
8
(0.31)
6
(0.24)
4
(0.16)
400
(15.75)
y
x
White background (90 % radiance factor)
Distance of sensor to background x = 150 mm
Required minimum object height y = 1.2 mm
For all objects regardless of their colors
6%/90%
90%/90%
2
1
6%/6%
90%/6%
Illustration 4: WTF12L-xxxxx1xx
0
Distance in mm (inch)
80 350
100
D
C
A B
BluePilot
E
F
Recommended sensing range for the best performance
100
(3.94)
200
(7.87)
300
(11.81)
400
(15.75)
Illustration 5: WTF12L-xxxxx1xx
A Distance de commutation min. en mm
B Distance de commutation max. en mm
C Champ de vision
D Plage de réglage seuil de commutation pour l’élimination de premier plan
E Indication de la distance de commutation
F Bouton poussoir rotatif
bleue Plage de distance de commutation recommandée pour la meilleure performance
