5.5 WT34-Bxxx, WT34-Vxxx
U
B
: 10 ... 30V DC, see "Technical data", page 34
Table 2: DC
WT34- B3x3 B2x0 V2x0 B4x0 V5x0
1 + (L+) + (L+) + (L+) + (L+) + (L+)
2 - (M) - (M) - (M) Test Test
3
Q/Q
- Alarm - (M) - (M)
4 -
Q/Q Q/Q Q/Q Q/Q
5 - Test Test - Alarm
I
N
= 4A
1 2 3 4 5
0.14 ...
1.5mm
2
I
N
= 4A
1 2 3 4 5
0.14 ...
1.5mm
2
I
N
= 4A
1
2
4 3
1
2
4 3
5
