Mower FA
- 3 -
CONTENTS
1. INTRODUCTION 5
1.1 SOME NOTES REGARDING THE USER MANUAL 5
1.2 DECLARATION OF CONFORMITY 6
1.3 GENERAL DELIVERY NOTES 7
1.4 MOWER IDENTIFICATION AND MANUAL CODE 8
1.5 TERMINOLOGY OF THE MAIN PARTS 9
2. SAFETY 10
2.1 LIST OF RESIDUAL RISKS 10
2.2 DEFINITIONS 10
2.3 CONVENTIONAL SYMBOLS 11
2.4 SAFETY PRESCRIPTIONS 11
2.5 OPERATOR REQUIREMENTS 12
2.6 CLOTHING AND PPE 12
2.7 SAFETY DEVICES 12
2.8 POSITION AND MEANING OF THE PICTOGRAMS 12
3. TECHNICAL SPECIFICATIONS 15
4. MACHINE USE 15
4.1 REASONABLY PREDICTABLE INCORRECT USE 16
4.2 UNLOADING AND UNPACKING THE MOWER 16
4.3 START-UP 17
4.4 ASSEMBLY 18
4.5 ATTACHING THE MOWER TO THE TRACTOR 19
4.6 PTO DRIVE SHAFT COUPLING 20
4.7 CHECK THE STABILITY OF THE TRACTOR-MOWER COMBINATION 21
4.8 ROAD TRANSPORT 21
5. ADJUSTMENTS 22
5.1 WORK HEIGHT ADJUSTMENT 22
5.2 ADJUSTING BELT TENSION 23
5.3 PREVENTIVE MAINTENANCE 23
5.4 PROCESSING 23
5.5 STOPS 25
6. CLEANING 25
7. STORAGE AND WINTERING 26
8. ROUTINE MAINTENANCE 26
8.1 CHECKING AND CHANGING THE OIL IN THE MULTIPLIER GEARBOX 27
8.2 GREASING 28
8.3 REPLACING THE TRANSMISSION BELTS 28
8.4 CHECK AND REPLACING THE BLADES 29
9. PTO DRIVE SHAFT 29
10. SCRAPPING 29
11. QUICK CONSULTATION TABLES 30
11.1 TABLE OF TIGHTENING TORQUES 30
11.2 TROUBLESHOOTING TABLE 31
11.3 MAINTENANCE TABLE 32
