Siemens 3TK2810-1 User Manual

Product description
2.4 Accessories
3TK2810-1 safety-related speed monitor
System Manual, 01/2011, 926246402000 DS 02
21
2.4 Accessories
The following accessories are available in addition to the main devices:
MLFB Designation
3TK2810-0A Cable for connecting with encoder/for copy function
3TK2810-1A Adapter for connecting with Siemens/Heidenhain encoder 15-pin
3TK2810-1B Adapter for connecting with Siemens/Heidenhain encoder 25-pin
The adapters (15-pin or 25-pin) are used as the connection between the encoder, the
controller and the standstill/speed monitor. They are designed for Siemens/Heidenhain
controllers with the following PIN assignments:
Signal SUB D15/SUB D25 RJ45
VCC 1 2*
GND 2 1
A 3 3
$
4 4
B 6 6
%
7 8
* Connection not absolutely necessary (not evaluated by device)
Further accessories:
Fixing lugs for mounting the device on a level surface. Per device 2 units are required.
Order No.: 3RP1903
