Siemens 3TK2810-1 User Manual

Technical data
8.1 Technical data
3TK2810-1 safety-related speed monitor
66 System Manual, 01/2011, 926246402000 DS 02
3TK2810-1BA41 3TK2810-1BA42 3TK2810-1KA41 3TK2810-1KA42
Operating range factor control
supply voltage rated value of the
solenoid
• at 50 Hz
– for AC
0.8 … 1,1
• at 60 Hz
– for AC
0.8 … 1,1
• for DC
0,9 … 1,1
Built in / Fixing / Dimensions
Built in orientation any
Type of mounting screw and snap-on mounting
Width mm 45
Height mm 105,9 107.7 105.9 107.7
Depth mm 124.3
Connecction
Design of the electrical connection screw-type
terminals
spring-loaded
terminals
screw-type
terminals
spring-loaded
terminals
Type of the connectable conductor
cross-section
• solid
mm²
0,5 ... 4
• finely stranded
– with wire end processing
mm²
— 2x (0,25 ... 1,5) — 2x (0,25 ... 1,5)
– without wire end processing
mm²
— 2x (0,25 ... 1,5) — 2x (0,25 ... 1,5)
• for AWG conductors
– solid
2x (20 ... 14) 2x (24 ... 16) 2x (20 ... 14) 2x (24 ... 16)
– stranded
2x (20 ... 14) 2x (24 ... 16) 2x (20 ... 14) 2x (24 ... 16)
