Siemens 6ES7153-2BA70-0XB0 - Response Time of the ET 200 M

Technical Specifications
10.5 Response time of the ET 200M
ET 200M
238 Operating Instructions, 04/2022, EWA-4NEB7806006-09
• Monitoring of the power supply voltage of the
electronics
Green "ON" LED
•
Maintenance demanded (maintenance)
Yellow "maint" LED
• Existing connection to network
one green LED "LINK" per port
•
Transmitting/receiving via network
one yellow LED "RX/TX" per port
10.5 Response time of the ET 200M
Response Time - A Definition
The response time is the time between detection of the input signal and the modification of
the associated output signal.
Duration
The response time depends on the bus structure and on the DP master / IO controller. Refer to
the DP master / IO controller manual for basics for calculating the response time.
Factors
The response time for the ET 200M depends on the following factors:
• Processing the data through the ET 200M
• Delay of the inputs and outputs (refer to the "S7-300 automation system, module
specifications (http://support.automation.siemens.com/WW/view/en/8859629)" reference
manual.
