Siemens 8DJH Series - Page 54

Description
54 Revision 03 * INSTALLATION AND OPERATING INSTRUCTIONS 8DJH * 500-8067.9
5.0-5.5 160 4 18.4 31.5 3-7.2 292 30 098 13.31,5
40 3-7.2 292 30 098 13.40
200 4 23 40 3-7.2 292 30 098 13.40
50 3-7.2 292 30 098 13.50
250 4 28.8 40 3-7.2 292 30 098 13.40
50 3-7.2 292 30 098 13.50
315 4 36.3 50 3-7.2 292 30 098 13.50
63 3-7.2 292 30 099 13.63
400 4 46.1 63 3-7.2 292 30 099 13.63
80 3-7.2 292 30 099 13.80
6 -7.2 20 4 1.9 6.3 6-12 292 30 004 13.6,3
6.3 3-7.2 292 30 098 13.6,3
6.3 6-12 442 30 101 13.6,3
30 4 2.8 6.3 6-12 292 30 004 13.6,3
6.3 3-7.2 292 30 098 13.6,3
6.3 6-12 442 30 101 13.6,3
50 4 4.8 10 3-7.2 292 30 098 13.10
10 6-12 292 30 004 13.10
10 6-12 442 30 101 13.10
16 3-7.2 292 30 098 13.16
16 6-12 292 30 004 13.16
16 6-12 442 30 101 13.16
75 4 7.2 16 3-7.2 292 30 098 13.16
16 6-12 292 30 004 13.16
16 6-12 442 30 101 13.16
100 4 9.6 16 3-7.2 292 30 098 13.16
16 6-12 292 30 004 13.16
16 6-12 442 30 101 13.16
20 3-7.2 292 30 098 13.20
20 6-12 292 30 004 13.20
20 6-12 442 30 101 13.20
125 4 12 20 3-7.2 292 30 098 13.20
20 6-12 292 30 004 13.20
20 6-12 442 30 101 13.20
25 3-7.2 292 30 098 13.25
25 6-12 292 30 004 13.25
25 6-12 442 30 101 13.25
160 4 15.4 31.5 3-7.2 292 30 098 13.31,5
31.5 6-12 292 30 004 13.31,5
31.5 6-12 442 30 101 13.31,5
200 4 19.2 31.5 3-7.2 292 30 098 13.31,5
31.5 6-12 292 30 004 13.31,5
31.5 6-12 442 30 101 13.31,5
40 3-7.2 292 30 098 13.40
40 6-12 292 30 004 13.40
40 6-12 442 30 101 13.40
250 4 24 40 3-7.2 292 30 098 13.40
40 6-12 292 30 004 13.40
40 6-12 442 30 101 13.40
50 3-7.2 292 30 098 13.50
Transformer HV HRC fuse
U [kV] S
N
[kVA] u
K
[%] I
1
[A] I
s
[A] U
s
[kV] e [mm] Order no.
