Appendix C Control Panel
Instructions for Use C - 3
Control Panel
(For systems without a touch screen)
The ultrasound imaging system has a combination of keys, rotary knobs, push and rotate
controls, and toggle controls. A trackball provides access to on-screen objects. The keys and
controls are logically arranged to require a minimum number of hand and eye movements. The
control panel also includes customizable keys.
Use the system configuration menu to assign the function of the customizable keys.
System Config > Print/Store
Control Panel Lighting
When the ultrasound system is in use, most controls on the main control panel are supported
by backlighting. Exceptions are noted in this chapter.
Color of Lighting Status
The control is active (in use).
White The control is inactive, but available for use.
No illumination The control is not available during the active function.
The alphanumeric keyboard on the control panel is also illuminated.
