Appendix E Advanced Feature Controls
E - 30 Instructions for Use
Maintenance
Dialog Box
Selection
Description
WMS Type
ASE 16 – 4
Scores or
ASE 17 –
4 Scores
Configures the system to display the indicated type of WMS graphics (16-segment or
17-segment) and the following wall motion scores for assignment:
X — Cannot evaluate
1 — Normal
2 — Hypokinetic
3 — Akinetic
4 — Dyskinetic
ASE 16 – 5
Scores or
ASE 17 – 5
Scores
Configures the system to display the indicated type of WMS graphics (16-segment or
17-segment) and the following wall motion scores for assignment:
X — Cannot evaluate
1 — Normal
2 — Hypokinetic
3 — Akinetic
4 — Dyskinetic
5 — Aneurysmal
ASE 16 – 7
Scores or
ASE 17 – 7
Scores
Configures the system to display the indicated type of WMS graphics (16-segment or
17-segment) and the following wall motion scores for assignment:
X — Cannot evaluate
1 — Normal
2 — Hypokinetic
3 — Akinetic
4 — Dyskinetic
5 — Aneurysmal
6 — Akinetic with scar
7 — Dyskinetic with scar
