Control via the operator panel
4.6 Menu commissioning / service
Cabinet Modules Operator Panel AOP30
50 Operating Instructions, 04/2014, A5E03263551A
VECTOR object
Table 4- 7 List of signals for the operation screen - VECTOR object
Signal
Parameter
Short name
Unit
Normalization (100%=...)
see table below
Factory setting (entry no.)
Speed setpoint upstream of ramp-function
generator
(1)
r1114 NSETP rpm p2000
Output frequency
(2)
r0024
F_OUT
Hz
Reference frequency
Power smoothed (3)
r0032 PACTV kW r2004
DC-link voltage smoothed
(4)
r0026
U_DC
V
p2001
Actual speed smoothed
(5)
r0021
N_ACT
rpm
p2000
Absolute actual current smoothed
(6)
r0027
I_IST
A
p2002
Motor temperature
(7)
r0035
1)
T_MOT
° C
p2006
Converter temperature
(8)
r0037
1)
T_LT
° C
p2006
Actual torque smoothed
(9)
r0031
M_ACT
Nm
p2003
Converter output voltage smoothed
(10)
r0025
V_OUT
V
p2001
1)
If a temperature sensor has not been installed, a value of –200° C is displayed.
Normalization for VECTOR object
Table 4- 8 Normalization for VECTOR object
Variable
Normalization parameters
Default for quick commissioning
Reference speed
100% = p2000
p2000 = Maximum speed (p1082)
Reference voltage
100% = p2001
p2001 = 1000 V
Reference current
100% = p2002
p2002 = Current limit (p0640)
Reference torque
100% = p2003
p2003 = 2 x rated motor torque
Reference power
100% = r2004
r2004 = (p2003 x p2000 x π) / 30
Reference frequency
100% = p2000 / 60
Reference modulation
depth
100% = Maximum output voltage without overload
Reference flux
100% = Rated motor flux
Reference temperature 100% = 100 °C
