Control via the operator panel
4.8 Operation via the operator panel (LOCAL mode)
Cabinet Modules Operator Panel AOP30
Operating Instructions, 04/2014, A5E03263551A
59
4.8.3
CCW / CW changeover
Settings: Menu – Commissioning/Service – AOP settings – Control settings
Switching between CCW/CW
(factory setting: No)
●
Yes
: Switching between CW/CCW rotation by means of the CW/CCW key possible in
LOCAL mode
●
No
: The CW/CCW key has no effect in LOCAL mode
For safety reasons, the CW/CCW key is disabled in the factory setting (pumps and fans must
normally only be operated in one direction).
In the "Operation" status in LOCAL mode, the current direction of rotation is indicated by an
arrow next to the operating status.
Note
You have to make additional settings when switching between CW/CCW rotation.
4.8.4
Jog
Settings: Menu – Commissioning/Service – AOP Settings – Control Settings
JOG key active
(factory setting: No)
●
Yes
: The jog key is effective in the LOCAL mode in the state "ready to power-up" (not in
"operation"). The speed that is set in parameter p1058 is approached.
●
No
: The JOG key has no effect in the LOCAL mode
4.8.5
Increase setpoint / decrease setpoint
You can use the Raise and Lower keys to enter the setpoint with a resolution of 1% of the
maximum speed.
Alternatively, the setpoint can also be entered via the numeric keys. To do so, press F2 in
the operation screen. The system displays an inverted edit field for entering the required
speed. Enter the required value using the numeric keypad. Press F5 "OK" to confirm the
setpoint.
Using the number keys, any speed ranging between the maximum speed (p1080) and
minimum speed (p1082) can be entered.
