Control via the operator panel
4.6 Menu commissioning / service
Cabinet Modules Operator Panel AOP30
Operating Instructions, 04/2014, A5E03263551A
53
Synchronization settings can be made under "Additional settings":
Synchronization
(factory setting: None)
●
None
The times for the AOP and drive unit are not synchronized.
●
AOP->Drive
– If you activate this option, the AOP and drive unit are synchronized immediately
whereby the current AOP time is transferred to the drive unit.
– The current AOP time is transferred to the drive unit every time the AOP is started.
– Depending on the set synchronization interval, the current AOP time is transferred to
the drive unit.
Note
Flashing "S"
If the AOP detects a difference between RAM and ROM during synchronization to the
drive unit, this is indicated by a flashing
"S" at the top right in the display or, if operator
input and/or parameter assignment has been disabled, by a flashing key symbol.
●
Drive->AOP
– If you activate this option, the AOP and drive unit are synchronized immediately
whereby the current drive unit time is transferred to the AOP.
– The current drive unit time is transferred to the AOP every time the AOP is started.
– Depending on the set synchronization interval, the actual drive unit time is transferred
to the AOP.
Note
Time-of-day master
The time
in the drive must be set by the time-of-day master (e.g. SIMATIC).
Synchronization interval
The interval for time synchronization is set from 1 hour (factory setting) to 99 hours.
For the interval, the time in the AOP from the time of the last change of the interval is
decisive.
