10 Adjustments
ARCADIS Varic / Orbic SPR2-310.842.01.07.02 Siemens AG
12.06 CS SD 24
Page 10 of 34
Medical Solutions
Load counter 2.2
Store load counter data
1. Switch on the system and insert a CD in the CD-ROM drive.
2. Open the service application.
3. Click on <Reports> and <Configuration Online>.
¹ A new report of the main system will be generated.
4. Click on <Exit> to close this window.
5. Click on <Eventlog> and <Burn Log-Files> in the service menu.
¹ A window appears “Do you want to burn a newly created developer SaveLog
too?”.
6. Click on <Yes> , <Select All> and <Burn Files>.
¹ All data will be burned on the CD, including the actual load counter data and the
event log.
NOTE
Replacing the D1 board (main system) sets the “reset counter”
and the load units to “0”.
Load counter reset
1. Install the new tube and enter the new single tank serial number under <Main Sys-
tem>-<Configuration>-<Load Counter>.
2. Under “Adjustment” click on <Load Counter>.
3. Click on <Go> to reset the load counter.
¹ A load counter reset is only possible after the new single tank serial number is
entered under <Main System>-<Configuration>-<Load Counter>.
4. Click on <Go> to end the reset of the load counter.
¹ The main system reboots
¹ A error message appears “Single Tank is not equal...”
NOTE
After a load counter reset, the serial number of the new tube is not
shown under <Main System>-<Adjustment>-<Load Counter> until
a “Generator Adjustment” has been performed.
5. Under “Adjustment” click on <Generator Adjustment> and perform a “Generator Adjust-
ment”
6. After the “Generator Adjustment” check whether the “Load Counter” reset has been
carried out.
¹ Check under <Main System>-<Adjustment>-<Load Counter> to see if the “single
tank serial number” has changed to the new tube serial number.
NOTE
Send the burned CD together with the single tank and the tube
questionnaire back to the factory (as required by the terms of the
warranty).
