Siemens Climatix Series Short Manual

From BMS
– Auto.
– Off
– Eco St1
–
– Comf.St1
–
– Eco St2
–
– Comf.St2
–
– Eco St3
–
– Comf.St3
Manual plant operation via HMI (only possible for
Tsp function = Stages+Tmp). Value can be set via
HMI even if communication is deactivated.
– Auto mode: The plant can be switched on via
time switch program, night cooling, etc.
– Plant switched off.
– Plant operating in Economy mode at stage 1 (using
setpoint stage 1 for analogue controlled plants).
– Plant operating in Comfort mode at stage 1 (using
setpoint stage 1 for analogue controlled plants).
– Plant operating in Economy mode at stage 2 (using
setpoint stage 2 for analogue controlled plants).
– Plant operating in Comfort mode at stage 2 (using
setpoint stage 2 for analogue controlled plants).
– Plant operating in Economy mode at stage 3 (using
setpoint stage 3 for analogue controlled plants).
– Plant operating in Comfort mode at stage 3 (using
setpoint stage 3 for analogue controlled plants).
External control
– Auto.
– Off
– Stage 1
– Stage 2
– Stage 3
Displays cuurrent command from external controller.
– Auto mode: The plant can be switched on via
time switch program, night cooling, etc.
– Plant switched off.
– Plant operating at stage 1 (using setpoint stage 1
for analogue controlled plants).
– Plant operating at stage 2 (using setpoint stage 2
for analogue controlled plants).
– Plant operating at stage 3 (using setpoint stage 3
for analogue controlled plants).
NightOpTemp.test
--- Starts plant to update sensor values for return-
air controlled plant and activated night cooling or
UnitStart TmpDelta.
(Temperature difference start). Jumps to page to
parameterize night kick.
Night cooling
--- Night cooling (free cooling). Jumps to page to
parameterize night cooling.
UnOcc mode
--- Starts plant at night based on temperature
difference. Jumps to page to parameterize
temperature difference start.
Boost
--- Boost plant start. Jumps to page to parameterize
boost plant start.
Powerup delay
0…36000 [s] Delayed plant start after controller restart.
Short Manual for Climatix Control System [v. 2.14.10, 2.14.20, 2.14.30 & 2.14.40]
SMCX.130215.02GB Page 10
