2.2.2 Supply air/extract air fan control
Fans can be directly controlled, pressure-controlled, flow controlled or controlled as
master-slave. Common or separate outputs are used depending on the
configuration.
Fans may include an alarm and/or active feedback contact.
Up to 3 setpoints per fan can be defaulted for controlled fans and achieving the
setpoints can be monitored.
You can influence the fan stage (speed) by room temperature, air quality, humidity,
outside air temperature or supply air temperature.
Operating hours are recorded separately. A message can be triggered upon reaching
a certain number of operating hours for the supply air fan.
Main menu > Unit > Fan control > Supply air fan
Main menu > Unit > Fan control > Extract air fan
Parameter Value Function
Actual value xx [l/s], [Pa] Depends on control type (Fan control mode), for
example actual pressure value.
Controller 0…10 0 [%] Actual controller value. Go to page for all
controller settings.
Output signal 0…10 0 [%] Actual value on output. Go to page for all settings
for analogue outputs.
Command – Off
– Stage 1
– Stage 2
– Stage 3
Actual fan mode. Go to page for all settings for
modulated digital outputs.
Main menu > Unit > Fan control > Supply air fan > Setpoints/Settings
Main menu > Unit > Fan control > Extract air fan > Setpoints/Settings
Parameter Value Function
Act.fan stage –
– Off
– Stage1
– Stage2
– Stage3
Actual fan mode.
– Off.
– Stage 1 (setpoint 1) active.
– Stage 2 (setpoint 2) active.
– Stage 3 (setpoint 3) active.
Act.setp.sa 0...100 [%]
0...40’000 [l/s]
0...5000 [Pa]
Depends on control type (fan control mode <> Direct or
DirectVar): Present calculated setpoint for fan.
Stage 1 0...100 [%]
0...40’000 [l/s]
0...5000 [Pa]
Depends on control type (fan control mode <> Direct
or DirectVar): Setpoint for stage 1 (TSP stages >= 1 for
controlled fans).
Stage 2 0...100 [%]
0...40’000 [l/s]
0...5000 [Pa]
Depends on control type (fan control mode <> Direct
or DirectVar): Setpoint for stage 2 (TSP stages >= 2 for
controlled fans).
Stage 3 0...100 [%]
0...40’000 [l/s]
0...5000 [Pa]
Depends on control type (fan control mode <> Direct
or DirectVar): Setpoint for stage 3 (TSP stages >= 3 for
controlled fans).
Max boost 0...(100 – highest setp.) [%]
0...(40’000 – highest setp.) [l/s]
0...(5000 – highest setp.) [Pa]
Depends on control type (fan control mode <> Direct or
DirectVar): Highest possible setpoint:
Setpoint for highest stage + Max boost [%], [l/s], [Pa]
(see also Fan compensation).
Min runtime 0…36000 [s] Minimum running time of fan after start.
Function
Parameterization
Short Manual for Climatix Control System [v. 2.14.10, 2.14.20, 2.14.30 & 2.14.40]
SMCX.130215.02GB Page 11

Siemens Climatix Series Specifications

General

Application	HVAC control
Communication Protocols	BACnet, Modbus, KNX
Inputs	Analog and digital inputs
Outputs	Analog and digital outputs
User Interface	web interface
Power Supply	24 V AC
Protection Class	IP20
Mounting	DIN rail mounting
