Siemens CP 443-1 User Manual

B4A−3
CP 443-1 Advanced for Industrial Ethernet / Manual Part B4A
Release 01/2007
C79000-G8976-C193-06
Contents
Contents − Part A
S7-CPs for Ind. Ethernet −
Configuring and Commissioning See General Part. . . . . . . . . . . . . . . . . . . . .
Note
Please remember that Part A of the manual also belongs to the description of the
CP. Among other things, it contains explanations of the safety notices, the
references to literature, and general information that applies to all S7 CPs for
Industrial Ethernet.
The version of the General belonging to this Part B of the manual is version
1/2005.
You can also obtain the current Part A from the Internet:
http://www4.ad.siemens.de/view/cs/en/8777865
Contents − Part B6
Notes on the Product B4A−2. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Contents B4A−3. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
1 Properties and Services B4A−6. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
2 Requirements for Use B4A−11. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
3 Installation and Commissioning B4A−14. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
3.1 Procedure / Steps in Installation B4A−14. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
3.2 C−PLUG (Configuration Plug) B4A−17. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
3.3 Module Replacement without PG B4A−19. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
4 Displays and Mode Selectors B4A−21. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
5 Performance Data B4A−24. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
5.1 General Characteristic Data B4A−24. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
5.2 Characteristic Data for S7 Communication B4A−24. . . . . . . . . . . . . . . . . . . . . . .
5.3 Characteristic Data for SEND/RECEIVE Interface B4A−25. . . . . . . . . . . . . . . .
5.4 Characteristics of Open TCP/IP Communication B4A−27. . . . . . . . . . . . . . . . . .
5.5 Characteristic Data for PROFINET IO B4A−28. . . . . . . . . . . . . . . . . . . . . . . . . . .
5.6 Characteristic Data for PROFINET CBA B4A−29. . . . . . . . . . . . . . . . . . . . . . . . .
5.6.1 Typical Values and Limit Values B4A−29. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
5.6.2 Cycle Times B4A−32. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
5.6.3 Reaction Times B4A−33. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
