Siemens CPU 1512SP-1 PN User Manual

View of the module
The figure below shows the CPU1512SP-1PN.
Figure 3-1CPU 1512SP-1 PN
Properties
The CPU1512SP‑1PN has the following technical properties:
Property Description Additional information
Supply voltage The 24VDC supply voltage is fed via a 4-pin
connection plug located at the bottom left on
the front panel of the CPU.
• Section Connecting (Page
21)
• ET 200SP System Manual
(https://support.industry.
siemens.
com/cs/ww/en/view/58649
293)
Standalone CPU You can also use the CPU1512SP-1PN in the
distributed I/O system ET 200SP as a "central
system" without a higher-level controller.
PROFINET IO
13
Product overview
3.2 Hardware properties
CPU 1512SP-1 PN (6ES7512-1DM03-0AB0)
Equipment Manual, 11/2022, A5E33591411-AE
