Property Description Additional information
PROFINET interface
(X1)
The interface has an integrated 3-port switch.
Port 1 and port 2 are located on the optionally
pluggable BusAdapter. Port 3 is integrated in
the housing of the CPU. You can connect the
PROFINETIO to the CPU via the BusAdapter.
You will find information on the BusAdapters
supported by the CPU in the section Connect
ing (Page 21).
In addition to PROFINET basic functionality, the
interface also supports PROFINET IO RT (real-
time) and IRT (isochronous real-time).
PROFINETIO communication or real-time set
tings can be configured. The basic functionality
of PROFINET supports HMI communication,
communication with the configuration system,
communication with a higher-level network
(backbone, router, Internet) and communica
tion with another machine or automation cell.
Port 1 and port 2 can also be used as ring ports
for the configuration of redundant ring struc
tures in Ethernet.
Operation of the CPU
as
• IO controller
• I-device
• IO controller:
As an IO controller, the CPU addresses the
connected IO devices
• I‑device:
As an I-device (intelligent IO device), the
CPU is assigned to a higher-level IO control
ler and is used in the process as an intelli
gent pre-processing unit of sub-processes
• PROFINET Function Manual
(https://support.industry.
siemens.
com/cs/ww/en/view/49948
856)
• ET 200SP System Manual
(https://support.industry.
siemens.
com/cs/ww/en/view/58649
293)
PROFIBUS DP
DP master To use the ET 200SP CPU as a DP master, you
need the CPU and the optional communication
module CM DP (PROFIBUS interface X2). When
used as a DP master, the ET 200SP CPU
exchanges data with the connected DP slaves
via PROFIBUS DP.
Intelligent DP slave (I-
slave)
To use the ET 200SP CPU as an intelligent DP
slave (I-slave), you need the CPU and the
optional communication module CM D
(PROFIBUS interface X2). As an I-slave, the ET
200SPCPU is connected via PROFIBUS DP to a
higher-level DP master and exchanges data
with it.
• PROFIBUS Function Manual
(https://support.industry.
siemens.
com/cs/ww/en/view/59193
579)
• Communication module CM
DP Equipment Manual
(https://support.industry.
siemens.
com/cs/ww/en/view/90156
526)
Accessories
NOTE
The CPU is delivered without a BusAdapter. You can find the article numbers of the supported
BusAdapters in the "Accessories/spare parts" section of the ET 200SP distributed I/O system
(https://support.industry.siemens.com/cs/ww/en/view/58649293) system manual.
14
CPU 1512SP-1 PN (6ES7512-1DM03-0AB0)
Equipment Manual, 11/2022, A5E33591411-AE
Product overview
3.2 Hardware properties
