Article number 6ES7512-1DM03-0AB0
–
Number of connectable IO Devices for
RT, max.
128
–
of which in line, max. 128
–
Number of IO Devices that can be sim
ultaneously activated/deactivated,
max.
8; in total across all interfaces
–
Number of IO Devices per tool, max. 8
–
Updating times The minimum value of the update time also
depends on communication share set for
PROFINET IO, on the number of IO devices, and
on the quantity of configured user data
Update time for IRT
–
for send cycle of 250 µs 250 μs to 4 ms; Note: In the case of IRT with iso
chronous mode, the minimum update time of
500 µs of the isochronous OB is decisive
–
for send cycle of 500 µs 500 μs to 8 ms; Note: In the case of IRT with iso
chronous mode, the minimum update time of
625 µs of the isochronous OB is decisive
–
for send cycle of 1 ms 1 ms to 16 ms
–
for send cycle of 2 ms 2 ms to 32 ms
–
for send cycle of 4 ms 4 ms to 64 ms
–
With IRT and parameterization of "odd"
send cycles
Update time = set "odd" send clock (any multiple
of 125 µs: 375 µs, 625 µs ... 3 875 µs)
Update time for RT
–
for send cycle of 250 µs 250 µs to 128 ms
–
for send cycle of 500 µs 500 µs to 256 ms
–
for send cycle of 1 ms 1 ms to 512 ms
–
for send cycle of 2 ms 2 ms to 512 ms
–
for send cycle of 4 ms 4 ms to 512 ms
PROFINET IO Device
Services
–
PG/OP communication Yes
–
Isochronous mode No
–
IRT Yes
–
PROFIenergy Yes; per user program
–
Shared device Yes
–
Number of IO Controllers with shared
device, max.
4
–
activation/deactivation of I-devices Yes; per user program
–
Asset management record Yes; per user program
2. Interface
Interface types
33
Technical specifications
CPU 1512SP-1 PN (6ES7512-1DM03-0AB0)
Equipment Manual, 11/2022, A5E33591411-AE
