Siemens CU240B-2 Applications Manual

Using SINAMICS G120 / G120C / S120 Blocksize converters in marine applications
Application Manual, 11/2019, A5E48346362A
9
Components for marine applications
3
The converters discussed in this Manual are based on the following components. They are
built-in types that are integrated in a control cabinet.
3.1 PM240-2 Power Modules
Table 3- 1 Overview of PM240-2 Power Modules
Voltage
Frame size (FS ...)
Power range (kW)
Integrated filter
1 AC / 3 AC 200 … 240 V
A
0.55 / 0.75
Class A (C2) / without
B
1.1 / 1.5 / 2.2
Class A (C2) / without
C
3 / 4
Class A (C2) / without
3 AC 200 … 240 V
C
5.5 / 7.5
Class A (C2) / without
D
11 / 15 / 18.5
--- / without
E
22 / 30
--- / without
F
37 / 45 / 55
--- / without
3 AC 380 … 480 V
A
0.55 / 0.75 / 1.1 / 1.5 / 2.2 / 3.0
Class A (C2) / without
B
4 / 5.5 / 7.5
Class A (C2) / without
C 11 / 15 Class A (C2) / without
D
18.5 / 22 / 30 / 37
Class A (C2) / without
E
45 / 55
Class A (C2) / without
F
75 / 90 / 110 / 132
Class A (C2) / without
G
160 / 200 / 250
Class A (C2) / C3
3 AC 500 … 690 V
D
11 / 15 / 18.5 / 22 / 30 / 37
Class A (C2) / without
E
45 / 55
Class A (C2) / without
F
75 / 90 / 110 / 132
Class A (C2) / without
G
160 / 200 / 250
--- / C3
The article numbers are completely listed in the following table.
Other Power Modules are not considered.
