Design of the frequency converter
2.3 Power Module
Converter with Control Units CU230P-2; CU240B-2; CU240E-2
Getting Started, 11/2013, A5E32885834B AA
17
2.3
Power Module
Which Power Module can I use with the Control Unit?
Control
Unit
Power Module
PM340
1AC
PM230 IP20 and
push-through
PM230
IP55
PM240
PM240-2
IP20
PM250
IP20
PM260
IP20
PM330
IP20
CU230P-2
---
✓
✓
✓
✓
✓
✓
✓
CU240B-2
---
✓
---
✓
✓
✓
✓
---
CU240E-2
✓
✓
---
✓
✓
✓
✓
---
PM230, 3 AC 400 V - Pump and fan applications
The PM230 Power Module with degree of protection IP20 and push-through is available
without a filter or with an integrated class A line filter.
The PM230 Power Module with degree of protection IP55 is available with an integrated
class A or class B line filter.
Order number range
•
IP55:
•
IP20:
•
Push-through
6SL3223
-0DE…
6SL3210
-1NE…
6SL3211
-1NE…
Frame size
FSA
FSB
FSC
FSD
FSE
FSF
FSGX
Power range (kW): IP20
0.37 … 3
4 … 7.5
11 … 18.5
22 … 37
45 … 55
75 … 90
---
Power range (kW): PT
3
7.5
18.5
---
---
---
---
Power range (kW): IP55
0,37 … 3
4 … 7,5
11 … 18,5
18,5 … 30
37 … 45
55 … 90
---
PM340, 1 AC 200 V - Standard areas of application
The PM340 Power Module is available without a filter or with an integrated class A line filter
with degree of protection IP20. The PM340 allows dynamic braking via an external braking
resistor.
Order number range: 6SL3210-1SB1…
Frame size
FSA
FSB
FSC
FSD
FSE
FSF
FSGX
Power range (kW)
0.12 … 0.75
--
--
--
--
--
---
PM240, 3 AC 400 V - Standard areas of application
The PM240 Power Module is available without a filter or with an integrated class A line filter
with degree of protection IP20. The PM240 allows dynamic braking via an external braking
resistor.
Order number range: 6SL3224-0BE… and 6SL3224-0XE…
Frame size
FSA
FSB
FSC
FSD
FSE
FSF
FSGX
Power range (kW)
0.37 … 1.5
2.2 … 4
7.5 … 15
18.5 … 30
37 … 45
55 … 132
160 … 250
