Page #48 background imageLoading...
Page #48 background image
Commissioning
4.2 Commissioning
Converter with Control Units CU230P-2; CU240B-2; CU240E-2
48 Getting Started, 11/2013, A5E32885834B AA
4.2.3
The most important parameters at a glance
Table 4- 1 Defining the interfaces of the frequency converter
Parameter
Possible settings
p0015
Macro drive unit
Define the pre-assignment for the inputs and outputs using one of the macros 1 to 22 (Section Selecting the
pre-assignment for the terminal strip (page 33”)).
Table 4- 2 Set fixed speeds
Parameter
Description
p1001
Fixed speed 1
p1002
Fixed speed 2
p1003
Fixed speed 3
p1004
Fixed speed 4
Table 4- 3 Set jogging
Parameter
Description
p1058
Jog 1
p1059
Jog 2
Table 4- 4 Selecting the fieldbus protocol
Parameter
Possible settings (selection options, depend on the CU type)
p2030 0: No protocol (this means: Control via digital inputs/connecting terminals)
1: USS
2: Modbus
3: PROFIBUS DP
4: CAN
5: BACnet
7: PROFINET
8: P1
