CHAPTER 3 | FCM2041-U3 OPERATOR INTERFACE MANUAL
MAINTENANCE MODE
3-9
Outputs When the box labeled Outputs is selected for DLC devices, the components section
of the screen displays the items that can be chosen. When the Outputs box is
selected for MLC devices, no components are available for individual selection—if
Outputs is selected, all MLC outputs are included. See Figure 3-14a for DLC/XDLC
devices and 3-14b for MLC devices. Items that can not be chosen are grayed out. (In
Figure 3-14a, LED is grayed out.) Make a selection of the components you wish to
arm, then press the OK soft key.
The Arm Output feature is not available for VESDA detectors. The OI has no control
over the VESDA output relays. There are no Arm Output menus for VESDA detectors.
Menu:Maint:Control:Arm:Settings
PHY:FireFinder@1, DLC@1, HFP11@2
Apply To
Components
Cancel OK
Inputs
LED
Devices
Relay 1
Outputs
Figure 3-14a Figure 3-14b
Arm Outputs Settings - DLC and XDLC Arm Outputs Settings - MLC
At this point, the components that were selected are not yet armed.
The Arm Outputs status screen returns. See Figures 3-15a and 3-15b. The compo-
nents that were selected are listed in the Components section of the screen. In
Figure 3-15a, the component is Relay 1; in Figure 3-15b, they are All Outputs. Press
the Execute soft key to arm the selected component.
Menu:Maint:Control:Arm
PHY:FireFinder@1, DLC@1, HFP11@2
Cancel Settings Execute
ARM OUTPUTS
AT: FireFinder@1, DLC@1, HFP11@2
COMPONENTS: Relay 1
Figure 3-15a Figure 3-15b
Arming Selected Outputs - DLC and XDLC Arming Selected Outputs - MLC
Control - ASD While in the Maintenance mode, navigate to the desired module/loop or device by
pressing the More Info/+ or
(FCM2041-U3) buttons.
Menu:Maint:Control:Arm:Settings
PHY:FireFinder@1, MLC@2, FP11@2
Apply To
Cancel OK
InputsDevices Outputs
Menu:Maint:Control:Arm
FireFinder@1, MLC@2, FP11@2
Cancel Settings Execute
ARM OUTPUTS
AT: FireFinder@1, MLC@2, FP11@2
COMPONENTS: All Outputs
