Building Technologies A6V10334410_h_en_--
Fire Safety 2015-09-29
No dust 4 mA
Low dust value 8 mA
Medium dust value 12 mA
High dust value 16 mA
Very high dust value 20 mA
0 μg/m³ 4 mA
30 μg/m³ 8 mA
60 μg/m³ 12 mA
90 μg/m³ 16 mA
150 μg/m³ 20 mA
Properties
With electrically isolated, passive two-wire 4…20 mA analog output.
The connection is independent of polarity.
The increment corresponds to the increment of the smoke indicator (bar graph
indicator). [➙ 24]
The error indicator can be suppressed with the 'FXS2051 ASD Configuration
Tool' software.
'Current loop' output.
