Page #77 background imageLoading...
Page #77 background image
Configuration
6
77
Building Technologies A6V10334410_h_en_--
Fire Safety 2015-09-29
6 Configuration
The aspirating smoke detector can be configured in two ways:
 Via the fire control panel and using the configuration software for the
FS20/FS720 (with limited configuration options)
 Using the 'FXS2051 ASD Configuration Tool' software
Values whose parameters were set from the fire control panel cannot be changed
with the 'FXS2051 ASD Configuration Tool' software. They are only displayed in
the 'FXS2051 ASD Configuration Tool' software.
A detector-dependent password must be entered locally on the aspirating smoke
detector to obtain writing rights on the aspirating smoke detector with the
'FXS2051 ASD Configuration Tool' software. The initial password is 1234. This
can be changed during installation. If you have lost the details of your password,
please contact the Customer Support Center.
Option via fire control panel
Standalone option
All parameters can be read with the
'FXS2051 ASD Configuration Tool' software.
All parameters can be read with the
'FXS2051 ASD Configuration Tool' software.
Certain parameters can be read from the fire
control panel.
Certain parameters can be configured from
the fire control panel.
All parameters can be configured with the
'FXS2051 ASD Configuration Tool' software.
Only those parameters that cannot be
configured from the fire control panel can be
configured with the 'FXS2051 ASD
Configuration Tool' software.
You will find more information on configuring the aspirating smoke detector with the
'FXS2051 ASD Configuration Tool' software in document A6V10332759. You will
find instructions for installing the driver in document A6V10348930.
You will find information about configuring with the software for the fire detection
system in document 009078 for fire control panels FC20xx and document
A6V10210424 for fire control panels FC72x.
See the chapter 'Applicable documents [āž™ 9]'.
You will find information about the parameters in the chapter 'Operating modes
[āž™ 39]'.
