Maintenance / Repair
8
Status queries with service devices
95
Building Technologies A6V10334410_h_en_--
Fire Safety 2015-09-29
3
4
5
1
2
Connecting the aspirating smoke detector to a PC
1 Aspirating smoke detector 4
Mini USB interface
2 Screw connection between housing cover and back box
5
Connection cable
3 Slide housing cover
Disconnecting connection between aspirating smoke detector and
PC
The PC is connected to the aspirating smoke detector and the software is
activated.
Changed settings and data are saved.
1. Close the software in the 'File' main menu with the 'Exit' command.
2. Remove the connection cable (5) from the aspirating smoke detector (1).
3. Slide the housing cover in the opposite direction to the arrow (3) and back into
its starting position.
The housing of the aspirating smoke detector (1) is closed.
