Siemens FDM221 - Setup and Function; Manual Call Point FDM221

3BSetup and function
4 Setup and function
4.1 Manual call point FDM221
The manual call point FDM221 triggers alarm when the glass pane is pushed in
(direct operation). The alarm is immediately transmitted to the control panel.
6
7
1
5
8
2
4
3
Legend
1 Housing bottom
2 LED
3 Switching unit
4 Terminals
5 Switching lever for test activation
6 Key with double function: Function test and opening housing
7 Alarm actuator (hammer)
8 Glass
