8BSpecifications
9.2 Dimensional drawings
9.2.1 Dimensions
FDM221, housing FDMH291-x FDM223/FDM224, housing FDMH293-x
9.2.2 Master gauge for recesses
FDM221, housing FDMH291-x FDM223/FDM224, housing FDMH293-x
9.3 Environmental compatibility
Electronic components and synthetic materials can be separated. The synthetic
material parts are identified and can be disposed of accordingly.
30
007002_e_en_--.doc
Fire Safety & Security Products 11.2007
