5BInstallation
6.2.2 Inserting the protective cover
When a protective cover is used, proceed as follows:
1. Open the housing.
2. Place the protective cover (1) in the lid (2) (see figure below).
3. Close the housing (3) with the lid (2).
FDM221
1
2
3
FDM223/FDM224
1
2
3
18
