Siemens FT2010 User Manual

PMI
Maximum number of events that can be displayed
4
15 | 40
Building Technologies
009310_l_en_
--
Fire Safety
2018
-
08
-
29
4 PMI
The figure below shows the PMI of the ↑ floor repeater terminal.
Figure 2: PMI of the floor repeater terminal
1 'ALARM' LEDs 7 'More alarms' button
2 Display 8 LED 'System On'
3 Navigation buttons 9 LED 'Remote alarm Active'
4 'Silence buzzer' button K LEDs and function keys, configurable
5 'Acknowledge' button S Key switch
6 'Reset' button
1
2
3
6
7
8
9
5
4
S
K
K
K
K
K
K
