6.6 Testing indicators
The 'LED test' is a functional HW check for the following indication elements:
● Display
● LEDs
The test takes 10 seconds and has two phases of 5 seconds each.
Testing the indicators and displays
κ Press <LED test>.
'LED test' phase 1 starts:
The complete display is white.
LEDs are in color mode 1.
'LED test' phase 2 starts:
The complete display is black.
LEDs are in color mode 2.
6.7 Indicating and scrolling in lists
'Events' and conditions, starting from the floor repeater terminal's configured
↑ visibility, are indicated in lists.
If a list contains several 'Events', you may scroll to the next list item by means of
the navigation buttons. The next 'Event' is highlighted.
' event list is open, the <
function of the button <▼>, changing to the next alarm event upon activation.
See also
1 Maximum number of events that can be displayed [➙ 14]
6.7.1 Show ALARM list
If an 'ALARM' occurs, the 'ALARM' list is automatically indicated.
If the 'ALARM' list contains several 'ALARMS', it is possible to go to the next alarm
event with the <More alarms> button.
The following representation shows an exemplary alarm event:
Fire Brigade requested
001 ALARM
––––––
Manual FIRE ALARM
Zone 1
––––––––––––––––––––––––––––––
–
Zone
–––––––––––––––––––––––––––
–––
1
––––
Alarm event
See also
1 Maximum number of events that can be displayed [➙ 14]
