6
19 | 40
Building Technologies
6 Operation
6.1 ALARM Procedure
If your fire detection system has no delayed alarm transmission function ('AVC'),
the variant –'Fire Brigade in' 'mm:ss' in Step 2 (see Procedure in the event of
alarm) does not apply.
Figure 4: ALARM operation sequence
1 <Acknowledge> 3 Indication of the fire location on the display
2 Top line on the display R <Reset>
The <Alarm delay off> button is not indicated as the command can be assigned to
each of the configurable buttons.
2
3
