Siemens H-compact PLUS - Upper Part of the Enclosure; Table 10-3 Spare Parts for the Upper Part of the Enclosure WPII; Figure 10-2 Upper Part of the Enclosure; Figure 10-3 Upper Part of the Enclosure WPII - Fig. 2

Spare Parts
10.6 Upper part of the enclosure
WOGeneric TEAAC / 2008
62 Siemens AG Operating Instructions 1.03 1RQ671...-Z
Part Description Part Description
17.051 Fastening elements 31.20 Cover for assembly hatch (with seal)
17.06 Cover plate for upper part of the enclosure
[ID 1160.00]
10.6 Upper part of the enclosure
Spare parts




Figure 10-3 Upper part of the enclosure WPII - fig. 2
Table 10-3 Spare parts for the upper part of the enclosure WPII
part Description part Description
31.10 enclosure 34.10 Coarse dust panel filter
31.20 Cover for assembly hatch with seal 34.25 Cover for service hatch
[ID 1040.00]
