Siemens H-compact PLUS - Terminal Box 1 XF4; Table 10-7 Spare Parts List for Terminal Box 1 XF4

Spare Parts
10.10 Terminal box 1XF4..
WOGeneric TEAAC / 2008
Siemens AG Operating Instructions 1.03 1RQ671...-Z 67
10.10 Terminal box 1XF4..
Spare parts
The neutral box only contains the neutral point. It is not permitted to install any additional
equipment.












Table 10-7 Spare parts list for terminal box 1XF4..
Part Description Part Description
20.20 Enclosure 21.43 Pin insulator, large
20.28 Seal 21.44 Pin insulator, small
20.30 Cover 22.30 Connecting bar for primary current
20.43 Pressure relief diaphragm 22.39 Neutral connection
20.50 Entry plate 22.92 Hexagon bolt and conical spring washer
21.30 Bushing for primary current, complete 22.93 Heating
