Spare Parts
10.9 Terminal box 1XE1...
WOGeneric TEAAC / 2008
Siemens AG Operating Instructions 1.03 1RQ671...-Z 65
part Description part Description
4.30 Locking ring 4.61 Inner bearing cover
4.35 Grease slinger 4.85 Grease feed
4.40 Cylindrical-roller bearing (floating bearing) 4.94 Fastening elements
4.50 Bearing housing 6.00 End shield, non-drive end
[ID 1052.01]
10.9 Terminal box 1XE1...
Spare parts
The neutral box only contains the neutral point. It is not permitted to install any additional
equipment.
The base plate is screwed on and is made out of steel. It is not permitted to use it as a cable
entry plate. If the terminal box is to be used as a connection box following conversion, a
brass plate should be used as the cable entry plate.
Conversion may only be undertaken following consultation with the person responsible for
the safety of the equipment and only original parts should be used.
