Siemens LOGO! 230RCL User Manual

131
LOGO! Manual
A5E00067781 01
Each parameter is identified by the block number and the
parameter abbreviation. Examples:
B01:T
Block number Parameter abbreviation
 T: ...is a time that can be set.
 No1: ...is the first cam of a time switch (clock).
 Par: ...refers to several counters that can be monitored.
5.1.2 Selecting a Parameter
To select a parameter, proceed as follows:
1. Select the ’Set Param’ option from the parameterization
menu.
Set Clock
>Set Param
2. Press the OK key
LOGO! displays the first parameter. If parameters can-
not be set, you can use ESC to return to the parameter-
ization menu.
Parameterizin
g
LOGO!

Siemens LOGO! 230RCL Specifications

General

Power Supply	230V AC
Input Voltage	230V AC
Digital Inputs	8
Analog Inputs	2
Programming Software	LOGO! Soft Comfort
Protection class	IP20
Mounting type	DIN rail
Digital Outputs	4
Operating Temperature	0°C to +55°C
Storage Temperature	-25°C to 70°C
