MJ-4 Communications Module
25
Binary Outputs
Point # Description
0 Control Raise (1=raise)
1 Control Lower (1=lower)
2 Remote Auto/Manual (1=block)
3 Fwd Voltage Level (+/-.1V) (0=dec, 1=inc)
4 Bandwidth Voltage (+/-.1V) (0=dec, 1=inc)
5 Fwd Time Delay (+/- 5s) (0=dec, 1=inc)
6 Fwd Reactive Comp (+/- 1V) (0=dec, 1=inc)
7 Local Voltage Reduct (1=Active)
8 Remote Volt Reduct (1=Active)
9 Local Volt Reduct % (+/-.5V) (0=dec, 1=inc)
10 Remote Volt Red. % (+/-.5V) (0=dec, 1=inc)
11 Fwd Resistive Comp (+/- 1V) (0=dec, 1=inc)
12 Reset Demands & min/max (AI 20-26)
13 Reset Energies (AI 27-28)
Analog Inputs
Point # Description
0 Operations Counter (100's)
1 Operations Counter (10's and 1's)
2 kVA Load
3 kW Load
4 Hardware Status (0=All Good)
5 Primary Load Current in Amps
6 Secondary Load Voltage
7 Primary Load Voltage
8 Primary Source Voltage
9 kVAR Load
10 Power Factor
11 Compensated Voltage (Sec.)
12 % Voltage Reduction in Effect
13 Tap Position
14 Voltage Reduction Status
15 Voltage Limit Status
16 Tap Control Mode Status
17 R/A/M switch position
18 Load Voltage Harmonics %
19 Load Current Harmonics %
20 Fwd Voltage Level Setting
21 Fwd Bandwidth Setting
22 Fwd Time Delay Setting
23 Fwd Reactive Compensation
24 Local Voltage Reduction %
25 Remote Voltage Reduction %
26 Fwd Resistive Compensation
27 Load Current Demand (fwd. max.)
28 KVAR Load Demand (fwd. min.)
29 KVAR Load Demand (fwd. max.)
30 KW Load Demand (fwd. max.)
31 Load Voltage Inst. Fwd. Min
32 Load Voltage Inst. Fwd. Max
33 Load Current Inst. Fwd. Max
34 KWHR Forward (0-999)
35 MWHR Forward (0-999)
